HOME > 제품소개 > 평철

  3T 4T 5T 6T 8T
STS STS STS STS STS STS STS STS STS STS
304/304L 316/316L 304/304L 316/316L 304/304L 316/316L 304/304L 316/316L 304/304L 316/316L
15MM 0.357 0.359 0.476 0.479 0.595 0.599 0.714 0.718
20MM 0.476 0.479 0.634 0.638 0.793 0.798 0.952 0.958 1.269 1.277
25MM 0.595 0.599 0.793 0.798 0.991 0.998 1.190 1.197 1.586 1.596
30MM 0.714 0.718 0.952 0.958 1.190 1.197 1.427 1.436 1.903 1.915
40MM 0.952 0.958 1.269 1.277 1.586 1.596 1.903 1.915 2.538 2.554
50MM 1.190 1.197 1.586 1.596 1.983 1.995 2.379 2.394 3.172 3.192
60MM 1.427 1.436 1.903 1.915 2.379 2.394 2.855 2.873 3.806 3.830
65MM 1.546 1.556 2.062 2.075 2.577 2.594 3.093 3.112 4.124 4.150
75MM 1.784 1.796 2.379 2.394 2.974 2.993 3.569 3.591 4.758 4.788
100MM 2.379 2.394 3.172 3.192 3.965 3.990 4.758 4.788 6.344 6.384

  9T 10T 12T 15T 20T
STS STS STS STS STS STS STS STS STS STS
304/304L 316/316L 304/304L 316/316L 304/304L 316/316L 304/304L 316/316L 304/304L 316/316L
15MM
20MM 1.427 1.436 1.586 1.596 1.903 1.915 2.379 2.394 3.172 3.192
25MM 1.784 1.796 1.983 1.995 2.379 2.394 2.974 2.993 3.965 3.990
30MM 2.141 2.155 2.379 2.394 2.855 2.873 3.569 3.591 4.758 4.788
40MM 2.855 2.873 3.172 3.192 3.806 3.830 4.758 4.788 6.344 6.384
50MM 3.569 3.591 3.965 3.990 4.758 4.788 5.948 5.985 7.930 7.980
60MM 4.282 4.309 4.758 4.788 5.710 5.746 7.137 7.182 9.516 9.576
65MM 4.639 4.668 5.155 5.187 6.185 6.224 7.732 7.781 10.309 10.374
75MM 5.353 5.387 5.948 5.985 7.137 7.182 8.921 8.978 11.895 11.970
100MM 7.137 7.182 7.930 7.980 9.516 9.576 11.895 11.970 15.860 15.960
